Product Information

Everything you need to know about each FlowStop, accessories, and modifications.

Compatibility

Make sure each opening is compatible with FlowStop.

Block or Brick wall

Please make sure the openings you are protecting are supported by block or brick walls. Setting a flood barrier on a stud wall will put the entire wall at risk of collapsing.

No Drywall

Even if you have a block wall behind your flood barrier should never be against drywall or sheet rock.

No Crawlspace

Even if you block the opening of the crawl space, it is very likely that the water will be siphoning from the ground and infiltrate your house. Flood barriers will slow down the water but not stop it.

Cracks, outlets, vents

Blocking the openings with Flood barriers is only the first step of a dryproof process. Please make sure you secure walls, outlets, pipes, vents, etc.

Wall surfaces

If your walls are too sleek (such as aluminum or painted wood), we will apply a gripping texture to the wall to provide a better grip.

If your wall is textured and has an inset larger than 1/3 of an inch, we will need to fill it up.

Compatible

If the grouts are less than 0.3"

Not
Compatible

Need
modifications

Full specs

Single-Chamber FlowStop

The single-chamber FlowStop is a barrier that pushes against four walls. It has a gasket on each of the four sides.
Best used for vents, windows, or protection against waves.
Please note that your barrier will not protect against more than 42 inches of floodwater.

Specifications

The single-chamber pushes against four walls.
Gasket on four sides.
Customized for any height.
Maximum width is 275".
Standard depths are 6" or 8", depending on width (see depth table).
When a 6" FlowStop won't fit, non-standard depths are also available, depending on width (see depth table).
Posts can be installed to increase the depth of the opening.

Depth Table

Double-Chamber Flowstop

The double-chamber Flowstop is a barrier that pushes against 3 walls. It has a gasket on both sides and the bottom.

Best Use for Door, Windows, garage door, Large opening

Please note, your barrier will not protect against over 40" of flood water.

Specifications

The double-chamber pushes against 3 walls
Gasket on 3 sides
Minimum height available is 31.5"
Standard depths are 6" or 8", depending on Width (See Depth Table)
When a 6" FlowStop won't fit, non-standard depths are also available, depending on Width (See Depth Table)
Requires Straps after a certain Width (See Straps table)
Available in specific heights (See Height Table)
2 Chambers that inflate separately
Posts can be installed to increase the depth of the opening.

Depth Table

Height Table

Screenshot 2026-03-09 at 12.02.45 AM.png

Strap Table

78" to 95"

1 STRAP

Place the strap 2" away from the valve.

95" to 135"

3 STRAPS

Add 2 straps 12" away from each edge.

Anchors tutorial

135" to 275"

5 STRAPS

Add 2 straps halfway between the central one and the one on the edge.
